Front Terminal FT AGM Battery Benefit
- Maintenance-free design with spill-proof construction
- AGM Battery, Rechargeable and can be mounted in any position
- 5-year design life, 1 years warranty
Front-Terminal AGM battery for telecommunication adopts high-tin alloy grid to enhance corrosion resistance of plates; pasted type thick plate to reduce the utilization of active material; AGM separator of high porosity, large aperture and high web-elasticity; tight assembling technology; patented terminal sealing construction and the cuing process of the adhesive at high temperature; FV-0 level flame retardant ABS material battery container; case formation technics and vacuum acid filling method; precise,quantitative,low temperature ,vacuum acid filling method; special gel electrolyte additives; advanced and environmentally friendly container formation technics ensures battery stable consistency.
Front-terminal VRLA battery mainly use at telecommunication and UPS system. The battery has the characteristic of long float charging life, excellent over-discharge tolerance, excellent cycling performance, stable consistency, large current discharge performance, low internal resistance, satety and etc.
RV and Caravan
Solar Panel Battery
Telecom Equipment
UPS or Backup Power
- Leisure Battery for your RV, Caravan, and Motorhome
- Marine Deep Cycle Battery, for trolling motors, navigational devices on boats (when the main motor is inactive)
- Solar and Renewable Industry
- Telecom Equipment
- UPS, EPS and Backup Power
- CCTV & Security System
- Electric Golf Carts
- Electric Wheelchairs
- Power Supply for devices at remote sites
- Ignition power sources for Automobiles
- Emergency Lighting systems
- Heavy Duty
- Powersports (Motorcycles, ATVs, Snowmobiles)
- Medical
FT AGM Battery Models
| 12V series | ||||||
| Model | Voltage(V) | Capacity(Ah) | Dimensions (L,W,H,Total Height*mm) | Weight(kg) | Terminal | mΩ |
| FT12-55 | 12 | 55 | 291*106*230*230 | 16.8 | M6 | 8.5 |
| FT12-55 | 12 | 55 | 291*106*230*230 | 18 | M6 | 7.5 |
| FT12-90A | 12 | 90 | 562*114*188*188 | 24 | M8 | 7 |
| FT12-90 | 12 | 90 | 562*114*188*188 | 26.5 | M8 | 5.8 |
| FT12-100A | 12 | 100 | 508*110*236*236 | 27 | M8 | 6.5 |
| FT12-100 | 12 | 100 | 508*110*236*236 | 28.5 | M8 | 6 |
| FT12-100A | 12 | 100 | 410*109*285*293 | 28.5 | M8 | 6 |
| FT12-100S | 12 | 100 | 410*109*285*293 | 31 | M8 | 6 |
| FT12-105A | 12 | 105 | 508*110*236*236 | 29 | M8 | 7.5 |
| FT12-105 | 12 | 105 | 508*110*236*236 | 32.5 | M8 | 6.5 |
| FT12-110A | 12 | 110 | 410*109*285*293 | 29.5 | M8 | 6.5 |
| FT12-110 | 12 | 110 | 410*109*285*293 | 31.2 | M8 | 6.5 |
| FT12-150A | 12 | 150 | 565*110*288*288 | 39.5 | M8 | 6 |
| FT12-150 | 12 | 150 | 565*110*288*288 | 43.5 | M8 | 5 |
| FT12-160 | 12 | 160 | 565*110*288*288 | 47 | M8 | 4.8 |
| FT12-180A | 12 | 180 | 560*125*316*316 | 48 | M8 | 4.8 |
| FT12-180 | 12 | 180 | 560*125*316*316 | 52 | M8 | 4 |
| FT12-185 | 12 | 185 | 560*125*316*316 | 54 | M8 | 4 |
| FT12-200A | 12 | 200 | 560*125*316*316 | 54 | M8 | 4 |
| FT12-200 | 12 | 200 | 560*125*316*316 | 57.5 | M8 | 4 |
FT AGM batteries Production Process
Lead Powder preparing
Vietnam Factory
Grid casting
Vietnam Factory
Lead ignot
Vietnam Factory
Fast delivery
Vietnam Factory
10 Pros of Front Terminal AGM Battery?
- Long Life: 12 years design life in floating condition
- Wide operating temperature range: from -15°C to 60℃
- Advanced paste formula with increased recharge efficiency
- Front access terminal with standard width for 19” and 23” ETSI racks
- 30% decreased float current lead to excellent high temperature resistance
- High purity lead-tin alloy, reduce battery self discharge rate and increase battery service life.
- Low self-discharge rate
- Excellent deep discharge recovery capability
- Battery can be installed in any position. Easy instalation and handling.
- Heat sealing technique instead of glue sealing to increase the tightness and stability of battery.
Brava Battery, one Front Teminal agm batteries supplier:
- Manufacturing base in Vietnam factory.
- Small QTY support,Accept mixed models for FCL order
- Extremely Competive price on Solar storage batteries
- Over 20 years experience in Lead-Acid battery industry
- Fast delivery,15-35 days
Vietnam factory
Vietnam Factory
Small QTY support
Vietnam Factory
20years experience
Vietnam Factory
Fast delivery
Vietnam Factory
Ask For A Quote
Small Quantity, OEM & ODM services are fully supported, please leave a message below.
For our specific models, please see front terminal AGM Battery.
